M330

Motor Type ............................... 1 HP Standard / 1.5 HP Optional (Belt Drive, Adjustable Sheave)
Power Input ............... V/Hz/Ph ...... 115 / 60 / 1 – Standard
.................................................. 230 / 60 / 1 – Optional
Air Flow .................... CFM .......... Up to 1,000
Cabinet Material ........... – ............. 16-Gauge Powder-Coated Steel, Chem-Resistant Enamel
Filtration Efficiency ...... % ............. MERV 13–14 (Based on Filter Selection)
Prefilter Options ............ – .............
– Two 12" x 24" x 2" Mist Impingers
– One 12" x 24" x 4" MERV 8 Pleated Filter
Primary Filter Options ...... – .............
– 12" x 24" x 26" MERV 14 Bag
– 12" x 24" x 26" MERV 13 Bag
– 12" x 24" x 12" Polypropylene ESF (MERV 13 or 14)
Filter Access ............... – ............. Standard Track Size Compatible with Multiple Media Types
Diagnostics ................. – ............. Dirty Filter Gauge + Power Indicator Light
Blower ....................... – ............. Belt Driven, Forward Curved
Drain Connection ............ – ............. Included for Oil/Coolant Return or Drain-Off
Mounting Options ........... – ............. Floor or Wall Mount (Optional Wall Arm)
Power Cord ................. – ............. 10 ft with Molded Plug
Dimensions (H×W×L) ....... in ............ Not Specified
Weight ...................... lb ............. 305 (Installed) / 340 (Shipping)

Standard Features
– Adjustable Sheave Blower for Application Flexibility
– Dirty Filter Gauge & Power Light
– Dual 8" Collars for Duct Configuration
– Drain Connection for Liquid Return
– 10 ft Molded Power Cord
– Compatible with Variety of Filter Media

Optional Features
– 1.5 HP Motor
– Wall Mount Arm
– One or Two 22 lb Odor Modules
– Multiple Primary Filter Options (Bag or ESF)
